Configuration and testing of IEC 61850 communications in Siemens SIPROTEC 5

About this course

This specialized training course provides engineers and technical professionals with essential knowledge and practical experience in configuring and testing IEC 61850 communications in Siemens SIPROTEC 5 devices. The program is designed to bridge the gap between theoretical understanding and real-world application, focusing on the most widely used communication services in modern digital substations. Participants will gain a clear and structured overview of IEC 61850 communication principles, followed by a practical demonstration of configuration in SIPROTEC 5 using GOOSE and MMS services. To ensure comprehensive understanding, the course also introduces Tekvel Magic software as a powerful tool for testing, validation, and troubleshooting IEC 61850 communications.

Course programme

• Introduction
• Creating a DIGSI 5 Project
• Adding Function Blocks
• Creating IEC 61850 Project
• GOOSE Publishing Configuration
• GOOSE Subscription Configuration
• Configuring the Information Routing Matrix
• Creating CFC Logic Diagrams
• Loading the Configuration into the Device
• Testing GOOSE
• Summary and Conclusions
